2-way Transmitter |
|
|
|
|
|
|
1-way Remote Control (option) |
|
|
|
|
|
|
Backup Siren |
|
|
|
|
|
|
Status LED |
|
|
|
|
|
|
Dual Shock Sensor |
|
|
|
|
|
|
Door Sensor |
|
|
|
|
|
|
Ignition ON sensor |
|
|
|
|
|
|
Tilt Sensor |
|
|
|
|
|
|
Hood Sensor |
|
|
|
|
|
|
Trunk Sensor |
|
|
|
|
|
|
Foot Brake Sensor |
|
|
|
|
|
|
Option Sensor |
|
|
|
|
|
|
Starter Kill (w/Relay) |
|
|
|
|
|
|
Panic Mode: Siren can be triggered intentionally |
|
|
|
|
|
|
Light Flash (w/Relay) |
|
|
|
|
|
|
Light Flash: ON/OFF |
|
|
|
|
|
|
Siren Time Selection: (15/30/60/90sec/OFF) |
|
|
|
|
|
|
Memory Function: If system senses unusual activities, notifies with number of chirp sound. |
|
|
|
|
|
|
Siren Stopping: Siren can be stopped without disarming |
|
|
|
|
|
|
Shut Down: System can be disarmed even in case of lost or stolen remote |
|
|
|
|
|
|
Shock Sensor Cancellation: Shock sensor can be cancelled as request |
|
|
|
|
|
|
Shock Sensor: ON/OFF |
|
|
|
|
|
|
Convenience Mode: Arm the system with engine running |
|
|
|
|
|
|
Silent Mode: Arm/disarm without chirp sound |
|
|
|
|
|
|
Chirp Sound: ON/OFF |
|
|
|
|
|
|
Re-lock Function: Auto rearm/relock after 30 sec, if door kept closed |
|
|
|
|
|
|
Passive Arming: Auto arm after 30 sec from closing doors |
|
|
|
|
|
|
Passive Door Lock: Auto door lock after 30 sec from closing doors |
|
|
|
|
|
|
System Valet Mode: All functions are cancelled except door interlock/aux output/panic mode |
|
|
|
|
|
|
Sensor Report: Records 10 events of sensor report |
|
|
|
|
|
|
LED Report: LED blinks in high speed if sensor detected |
|
|
|
|
|
|
System Check: Checks communication range by remote |
|
|
|
|
|
|
Option Sensor: ON/OFF |
|
|
|
|
|
|
Ajar Detector: Chirp sound will notify incase door is not closed |
|
|
|
|
|
|
Door Lock Output (w/Relay): Door lock/unlock will be linked with systems arm/disarm |
|
|
|
|
|
|
IG Door Interlock: Door lock/unlock can be linked with IG ON/OFF. |
|
|
|
|
|
|
Dome Light Setting: Dome light can be set to turn ON when disarm |
|
|
|
|
|
|
Trunk Open: Opens trunk by remote |
|
|
|
|
|
|
Auxiliary Output: Controls connected auziliary accessories by remote |
|
|
|
|
|
|
Clock Display |
|
|
|
|
|
|
Alarm Function: Beep sound alarms at set time |
|
|
|
|
|
|
Beep Sound Setting: (High/Low) |
|
|
|
|
|
|
Low Battery Alarm: Beep sound with low battery display for reminder |
|
|
|
|
|
|
Button Lock |
|
|
|
|
|
|
Vibration |
|
|
|
|
|
|
Temperature Display: Displays vehicle inner temperature |
|
|
|
|
|
|
Vehicle Finder: Useful to find location of vehicle |
|
|
|
|
|
|
Parking Timer: Displays parked time. |
|
|
|
|
|
|
Remote Engine Start |
|
|
|
|
|
|
Engine Start Time Setting: Run time selection (5/10/20/30mins) |
|
|
|
|
|
|
Light Flash Setting (at EG start): ON/OFF |
|
|
|
|
|
|
Turbo Timer: Ideling duration after IG OFF(30sec/60sec/OFF) |
|
|
|
|
|
|
Low Battery: Recharges vehicle battery when voltage is under 11.3V for more than 1 min |
|
|
|
|
|
|
Remote Start/Turbo Timer Combo: Compatible to vehicles with engine start/turbo timer |
|
|
|
|
|
|
Timer Engine Start: Engine can be started at set time |
|
|
|
|
|
|
Cold Engine Start: Engine starts every 1/2/3hours to prevent the radiator from freezing in cold |
|
|
|
|
